This depends on the application – power MOSFETs are available with breakdown ratings as low as 20V and as high as 1200V, and currents ranging from milliamps to kiloamps, a full six decades. There are a few important points considerations when using a MOSFET as a switch.ĭrain-to-source breakdown voltage and drain current: However, like the BJT, this property is not linear, that is, the resistance does not decrease linearly with applied gate voltage, as shown in the below figure from the datasheet of the popular IRF3205, while we are talking about internal resistance heat plays a key role when it comes to internal resistance.įor the most part, this does not matter, since power MOSFETs are intended to be used for switching applications, though linear use is possible. The MOSFET can be thought of as a voltage-controlled variable resistor, just like the BJT transistor can be considered a current-controlled current source. Most power MOSFET schematic symbols are drawn showing the parasitic diode. Technically speaking, a FET is inherently bidirectional, but the way power MOSFETs are constructed on the silicon-level adds a parasitic anti-parallel diode across the drain and source, which makes the MOSFET conduct when the voltage across it is reversed, which is something to keep in mind. Like Bipolar Junction Transistor or BJT, MOSFET is a three-terminal device, the three terminals being the GATE, the drain, and the SOURCE, with the gate controlling the conduction between the drain and source terminals. In one of our previous articles, we have discussed What is MOSFET: Its Construction, Types, and Working you can check that out if you want t to learn about the basics of a MOSFET. So, in this article, we will talk about different ways to switch on and off a MOSFET and in the end, we will look at some practical examples that show how this affects the MOSFET. MOSFETs are preferred for their low conduction losses, low switching losses, and as the gate of the MOSFET is made out of capacitors it has a zero DC gate current. Almost all modern-day switching supplies use some form of power MOSFETs as their switching elements.
Ever since the advent of the power MOSFET in the 1980s, power switching has become faster and more efficient. Depending on this gate voltage we can change the conductivity and thus we can use it as a switch or as an amplifier like we use a Transistor as a switch or as an amplifier. Similarly, the gate voltage determines the conductivity of the device. For simplicity, you can imagine this gate as like a water tap you rotate the tap counter-clockwise the water starts flowing out of the tap, you rotate it clockwise water stops flowing from the tap. MOSFET stands for Metal Oxide Semiconductor Field Effect Transistor, which has a gate. MOSFET is a transistor that uses field effect.
